35
3.8.1 SMBC
Select Application >> SMBC, configure Samba client function.
Table 3-8-1 SMBC Parameters
SMBC
Function description: configure parameters for SMBC
Parameters
Description
Default
Enable SMBC
Enable SMBC function
disable
SMBC Configuration
MAC address
Select or enter LAN device address
manually
00:00:00:00:00:00
IP address
Corresponding IP address
N/A
Description
Description of the device
N/A
3.9 STATUS
3.9.1 System
From navigation tree, select Status >> System, then enter the “System” page.
This page displays system statistics, including name, model, serial number, description, current
version, current Bootloader version, router time, PC time, UP time, CPU load and memory
consumption. Allow to click the <Sync Time> button to synchronize the router with the system
time of the host, as covered in the set-up chapter.
3.9.2 Modem
From navigation tree, select Status >> Modem, then enter the “Modem” page.
This page displays the basic information of dialup, including status, signal level, register status,
IMEI (ESN) code, IMSI code, LAC and cell ID.
3.9.3 Traffic Statistics
Choose Status >> Traffic Statistics to go to the "Traffic Statistics" page to query traffic statistics.
