Innovative Technology BV30 - Page 27

BV30 User Manual – 26
Pin Name Type Description
2
Factory Use Only – Do Not Connect
3
4
5 Inhibit1 Input SerialData In (Rx)
6
Factory Use Only – Do Not Connect


7
8
9
10
11
12
13
14
15 +Vin Power +12VDCSupply
16 0V Power 0VSupply (GND)
IF5 Interface
An BV30 running MDB can use an IF5, an external interface box, which regulates the power supply and opto-isolates
the communication lines. Typically the vending machine’s power supply is a higher voltage than the maximum for
the BV30. The IF5 drops this higher voltage down to the required level.
