BV30 User Manual – 28
Pin Assignments
Pin Name Type Description
1 Vend1 Output CreditOutput Channel 1
2 Vend2 Output CreditOutput Channel 2
3 Vend3 Output CreditOutput Channel 3
4 Vend4 Output CreditOutput Channel 4
5 Inhibit1 Input InhibitInput Channel 1 by
holding HIGH, hold LOW to
enable
6 Inhibit2 Input InhibitInput Channel 2 by
holding HIGH, hold LOW to
enable
7 Inhibit3 Input InhibitInput Channel 3 by
holding HIGH, hold LOW to
enable
8 Inhibit4 Input InhibitInput Channel 4 by
holding HIGH, hold LOW to
enable
9 Busy Output OutputBusy Signal. Active
LOW when BV30 is in
transporting, reading or
stacking anote
10 Escrow Input InputEscrow Control.
Enable escrow function by
holding LOW
11
Factory Use Only – Do Not Connect

12
Parallel is an unsecure interface and should not be used for new developments!
