Pin Name Type Description
13
14
15 +Vin Power +12VDCSupply
16 0V Power 0VSupply (GND)
Inhibit Control
The Inhibits can be used to either enable or disable the acceptance of those banknotes programmed on channels 1,
2, 3 and 4. The Inhibits are internally held high and must be set to low (GND) to enable banknote acceptance. If no
Inhibit is set to low (GND) the Master Inhibit is set and the BV30 is disabled.
Escrow Control
The BV30 has a single note escrow facility. This allows the BV30 to hold onto the note once validated, and then only
accept the note when the host machine confirms that the Vend operation has been completed. Hold pin 10 LOW to
enable the single note escrow function. If the host machine aborts the transaction by setting the corresponding
inhibit input HIGH, the note is returned immediately.
Please refer to Escrow Timing Diagram for timing diagram and further details.
Busy Control
This is a general-purpose busy signal. It is active low (pin 9) while the BV30 is in operation.
Low Power Mode
The Low Power Mode can be used to reduce the power consumption of the BV30 when idle. When the Low Power
Mode option is set, the BV30 goes into the Low Power Mode after about 6 seconds after the BV30 is powered up and
remains in this state until a note is entered. Following a note insertion, the BV30 returns to Low Power Mode
approximately 1 second after a credit is given or note is rejected. Please refer toLow Power Mode Timing
Diagramfor timing diagram and further details.
IF10
The IF10 is an interface that allows serial SSP to be used in machines without the need to update the host machine
software. The IF10 is connected between the BV30 and the host machine. The IF10 communicates with the BV30 in
serial SSP which gives more security along the length of the cable. The IF10 should be mounted close to the host
machine control board where the IF10 converts to the parallel connection.
InLow Power Mode,the front sensor is checked every second which can lead to a delay in accepting the
note when it is presented!
Configuration button functions are only available during power up before the BV30 goes into Low Power
Mode!
