Method & Equipment Used
Method
BV30 downloaded with the latest firmware provided
Oscilloscope connected to the BV30 Channel 1 with Current Probe and Channel 2 with the Voltage Probe
Probes attached to the power lead
Open, Open Choice Desktop and connect to the oscilloscope
Starting with power up, the waveform is captured on Open Choice desktop and saved
Power off, Idle, Pay In, Pay Out and Jam waveforms also saved
Equipment
3 x BV30
NVTools v2.6.2
cf1 firmware
BRL Notes
Tektronix MSO 3014 Oscilloscope
Tektronix Open Choice Desktop
Tektronix TCP0020 Current Probe
Tektronix P6139B Voltage Probe
Power Supply & Cables
Conclusion and Recommendations
BV30 operating within product specification
Compiled By
Brian Doyle
