NOTES:
• All outputs are open collector transistors.
• All Inputs are held high to internal +5V via 10KΩ. The input structure is a
CMOS gate with anti-static protection fitted.
Interface logic levels Logic low Logic high
Inputs 0V <low<0.5V 3.7 V <high<12V
Outputs with 2K2Ω pull up
0.6V Pull up voltage of host interface
Maximum Current Sink 50mA per output
Table 6 - Interface Logic Levels
5.3 SERIAL INTERFACE INPUT AND OUTPUTS
CAUTION: THE SERIAL INTERFACES WILL ONLY WORK IF THE RELEVANT INTERFACE
SOFTWARE IS CORRECTLY INSTALLED.
Name Description
SSP TxD Vend 1
SSP RxD Inhibit 1
Table 7 - Serial Interface Inputs and Outputs
