2
CONTENTS
1 Introduction 3
2 Environment and power requirements 5
3 General description 6
4 NV10 user interface 7
4.1 DIPswitch settings 8
4.2 LED Status codes 8
5 Machine Interface: hardware 9
5.1 Interface connector pin details 9
5.2 Input and output hardware circuits 10
5.3 Serial interface input and outputs 11
6 Machine interfaces: protocols 12
6.1 Parallel input and output 12
6.2 Pulse stream output 12
6.3 Binary output - BIN 13
6.4 Serial input/output – SIO (Baud rate is defaulted to 300) 14
6.5 Serial input/output – SI2 (Baud rate is defaulted to 9600) 17
6.6 Smiley
®
Secure Protocol (SSP) 18
6.7 Multi-Drop Bus / internal communications protocol (MDB/ICP) 19
6.8 ccTalk
®
protocol - CCT 20
6.9 Cash code serial protocol 21
6.10 Non-isolated serial protocol (NIS) 22
7 Updating currency and firmware files 22
7.1 ITL Bank Note Validator Currency Manager 22
7.2 NV10 – NV10 copy (cloning) 23
8 Mechanical installation 25
8.1 Changing or removing the bezels 25
8.2 Fitting the bezel into a machine 25
9 Routine maintenance 26
9.1 Cleaning 26
9.2 Belt changing 28
10 Fault finding analysis 29
11 Support tools 30
11.1 PC programming software (ITL Bank Note Validator Currency Manager) 30
11.2 Validator programming system (DA3) 30
11.3 Internet website support 30
11.4 E-mail support 30
Appendix 31
Appendix A –Dimension drawings 31
Appendix B – Extended bezels 32
Appendix C –Cash box advice 33
Appendix D - Escrow control 34
Appendix E - Interface tools DA1 – DA2 35
Appendix F – PC system specification 37
Index 38
Copyright Innovative Technology Ltd 2008 GA333-5
