Note entered into validator Validator Busy 120
Note accepted channel 2 Validator Ready 121
Accept on channel 2 2
Note entered into validator Validator Busy 120
Note not recognised Validator Ready 121
Note not recognised 20
Validator has returned note Validator Ready 121
Software Inhibit Channel 4 Inhibit C4 134 Inhibit C4
Channel 4 inhibited 134
Software Enable Channel 4 Uninhibit C4 154 Uninhibit C4
Channel 4 inhibited 154
Status Report 182 Status Request
Status Requested 182
3 byte status message Inhibit status Channels 1-8 Byte 1
Inhibit status Channels 9-16 Byte 2
Escrow On (=1) / Off (=0) Byte 3
Turn on Escrow Mode 170 Enable Escrow
Mode
Escrow Mode Enabled 170
Note accept in Escrow Mode
Note entered into validator Validator Busy 120
Note Accepted Channel 2 Validator Ready 121
Accept on Channel 2 2
172 Accept Note in
Escrow
Accept Escrow 172
Accept on Channel 2 2
Table 9 – Example protocols
6.5 SERIAL INPUT/OUTPUT – SI2 (BAUD RATE IS DEFAULTED TO 9600)
This mode is identical to the SIO mode detailed in chapter 7.4 with the exception of the
Baud rate used and the data format.
• Only 9600 baud rate is available.
• Inhibit 2 has no function.
• All Transmit and Receive codes and Example protocols are the same as in
Chapter 6.4 (See tables 8 and 9 above)
The data is formatted as follows:
1
