NV10 Operations Manual 22
.10 NON-ISOLATED SERIAL PROTOCOL (NIS)
position to select ‘Special’ mode
here is a single output DATA line from the NV10. There are three control lines, two from
AUTIONS:
6
To use NIS mode DIPswitches 3 and 4 must be in the Up
on the validator and the NIS option of the interface firmware must be loaded into the
NV10. (DIPswitch 2 is not functional in this mode).
T
the controller ‘’ACCEPT ENABLE’’ and ‘’SEND’’ and one from the Validators IRQ
(INTERRUPT) (see table 10).
C
 PLEASE NOTE THAT THE NV10 IS REQUIRED TO OPERATE ON A +12VOLT
OUND MUST BE CONNECTED TO THE GROUND OF THE
t i on this protocol please refer to the series 2000 interface manual
DC POWER SUPPLY.
 THE NV10 GR
CONTROL SYSTEM.

For further de a ls
(reference number 20105-002850046-PS), or contact
support@innovative-
technology.co.uk
.
Connection Details:
Copyright Innovative Technology Ltd 2008 GA333-5
Signal NV10
+12V 15
0V 16
ACCEPT ENABLE 6
SEND 7
IRQ (INTERRUPT) 2
DATA 1
OUT_OF_SERVICE 3
Table 10 - Extended Interface USA Serial
UPDATING CURRENCY AND FIRMWARE FILES
Note: Validators are supplied already programmed from the factory Please skip this
he NV10 Validator may only be programmed using the ITL Bank Note Validator Currency
.1 ITL BANK NOTE VALIDATOR CURRENCY MANAGER
are, which is supplied
ere new releases
7
section unless the validators need to be re-programmed with a new note or currency.
T
Manager 2.9.7 or greater or by cloning from a master unit:
7
In order to use the ITL Bank Note Validator Currency Manager softw
with a range of currencies, it must be installed from the DA1/DA2 CD or by downloading
from the web site. For the PC System Specification refer To Appendix F.
A list of currently supported currencies is maintained on our web site, wh
can be downloaded. Further details are available from support@Innovative-
technology.co.uk
