2 ENVIRONMENT AND POWER REQUIREMENTS
ENVIRONMENT
POWER REQUIREMENTS
Environment
Minimum
Maximum
Temperature +3ºC +50ºC
Humidity 5% 95% Non condensing
Table 1 – Environmental Requirements
CAUTIONS:
IF THE INPUT VOLTAGE FALLS BELOW +11V, THE NV10 MAY NOT OPERATE CORRECTLY
(THE VALIDATOR WILL REJECT NOTES). THE AMBER STATUS LED AND FRONT BEZEL
LIGHTS WILL FLASH TO INDICATE INCORRECT CONDITIONS.
IT IS ESSENTIAL THAT THE POWER SUPPLY USED CAN SUPPLY AT LEAST 1.5 AMPS.
Table 2 – Power Requirements
Electrical Supply Minimum
Maximum
Supply Voltage (V DC)
Absolute Limits
+11 V +15 V
MDB IF5 Version Supply
Voltage
+18V +42V
Supply Ripple Voltage 0 V 0.25 V @ 100 Hz
Supply Currents:
Standby 0.35 A
Validating 1 A
Peak (Stacker Motor Stall) 1.5 A
