Cloning process.
• Master unit will flash RED and GREEN LED if the connector is configured
ctly.
.
i
AU TO SLOW BLINK (1 PER SECOND) THEN
N HAS BEEN LOST AND COPYING SHOULD BE RESTARTED FROM
ause
urrency copy:
AUTION: IF MASTER RED LED CHANGED TO SLOW BLINK (1 PER SECOND) THEN
N HAS BEEN LOST AND COPYING SHOULD BE RESTARTED FROM
ss (the
corre
• RED and GREEN on master flash together – attempting to communicate
with slave.
• RED and GREEN on master flash alternately - communication established,
master waiting for slave to reset.
• If communication has been established and slave has reset then the
master will read slave firmware version and decide on next action.
• If the master is not compatible with the slave, Master RED and GREEN LED’s
will flash alternately at 1-second rate. No further copy action will take place
• If slave firmware version is greater than master, Master RED and GREEN
LED’s will flash alternately at 1-second rate. No further copy action will take
place.
• If slave firmware version is same as master then master will start to copy
currency data to slave.
• If slave firmware version is less than master then master will start to copy
firmware data to slave.
F rmware copy:
TION: IF MASTER RED LED CHANGESC
COMMUNICATIO
BEGINNING.
• Master RED LED will blink rapidly during firmware copy (the LED will p
from time to time).
• If master RED LED changed to slow blink (1 per second) then communication
has been lost and copying should be restarted from beginning.
• When firmware copy is complete, slave will reset and Master unit will wait to
re-establish communications. (LED flashes as at first stage power-up).
• When slave is ready, master will initiate currency data copy.
C
C
COMMUNICATIO
BEGINNING.
• Master GREEN LED will blink rapidly during the currency copy proce
LED will pause from time to time).
• When currency copy is complete, Master will show GREEN and RED LED’s
continuously and slave will reset.
• NV10 – NV10 copy is now complete.
NV10 Operations Manual 24
