MD320/MD320N User Manual Function Parameter Table
85
Function
code
Name LED display Set range
Minim-
um unit
Factory
default
value
Modication
description
F9-13
Output
phase-failure
protection
selection
Output
phase-failure
selection
0: Inactive
1: Active
1 1
☆
F9-14
The rst fault
type The second
fault type 1
0: No fault
1 : I n v e rt e r u n i t p r o te c t i o n
(ERR01)
2: Speed-up over current(ERR02)
3 : S p e e d - d o w n o v e r
current(ERR03)
4: Constant speed over current
(ERR04)
5: Speed-up over voltage(ERR05)
6 : S p e e d - d o w n o v e r
voltage(ERR06)
7 : C o n s t a n t s p e e d o v e r
voltage(ERR07)
8 : C o n t r o l p o w e r s u p p l y
fault(ERR08)
9: Under voltage failure (ERR09)
10: Inverter overload (ERR10)
11: Motor overload (ERR11)
12: Input phase failure (ERR12)
13: Output phase failure (ERR13)
14:Radiator over heat(ERR14)
15: External fault(ERR15)16:
Communication fault (ERR16)
17: Contactor fault(ERR17)
1 8 : C u r r e n t d e t e c t i o n
fault(ERR18)
19: Motor tuning fault (ERR19)
20: PG fault(ERR20)
21: Data overow (ERR21)
2 2 : I n v e r t e r h a r d w a r e
fault(ERR22)
23: Motor to earth short circuit
fault(ERR23)
24: Reserved (ERR24)
－ － ●
F9-15
The second
failure type
The second
failure type 2
－ － ●
F9-16
The last
failure type
The third fault
type
－ － ●
F9-17
Frequency
upon fault
Frequency
upon fault
－ － － ●
F9-18
Current upon
fault
Current upon
fault
－ － － ●
F9-19
Bus voltage
upon fault
Bus voltage
upon fault
－ － － ●
