Standards Compliance
‑128‑
● Equipment Category C4: PDS of rated voltage equal to or above 1000 V, or rated
current equal to or above 400 A, or intended for use in complex systems in the
second environment
7.2.3 Conditions for Compliance with the LVD
This product has been tested according to EN61800‑5‑1, and it complies with the Low
Voltage Directive (LVD) completely. To enable machines and devices integrating this
drive to comply with the LVD, the following requirements must be met.
Installation Location
Place this product in a location meeting OVC III and PD 2 or below, as specified in IEC
60664‑1.
Installation Environment
For installation environment requirements, see "Installation Environment" in
Quick
Start Guide (Installation & Commissioning)
.
Requirements on Installation and Protection
● This product must be installed in a fireproof cabinet with doors that provide
effective electrical and mechanical protection. The installation must conform to
local and regional laws and regulations, and to relevant IEC requirements.
● When installing the product in a cabinet (IP20), install it in structures that cannot
be accessed by foreign objects from the top and front.
Main Circuit Wiring Requirements
For details, see "
3.1.2 Main Circuit Wiring Requirements
"
on page 46Main Circuit
Wiring Requirements
.
Requirements on Protective Devices
To meet the requirements of EN 61800‑5‑1, a fuse/circuit breaker must be connected
on the input side to prevent accidents caused by internal short circuits. For details
about the selection of the fuse/circuit breaker, see "
4.1.1 Fuse, Circuit Breaker, and
Contactor
"
on page 94Fuse, Circuit Breaker, and Contactor
.
7.3 UL or cUL Certification
Figure 7‑2 UL/cUL Mark
