6 Parameter Description
-
205
-
changes from valid to invalid, and elevator cannot be started.
2) When the wire holder resetting output signal is valid, the elevator doors cannot
be opened or closed, and the elevator cannot be started. To enable this function,
set Bit14 of F6-52. By default, this function is disabled.
■
26: Braking pipe short circuit output
Output when the controller braking pipe is short-circuited.
■
limit.
Function
Code
Name Setting Range Default Unit Property
F5-32
Communication
status
CANbus and Modbus
communication state
monitoring
- -
It is used to monitor the state of CANbus communication with the CTB and Modbus
communication with the HCB.
When you enter the menu of F5-32, the LEDs on the operation panel indicate the
current HCB communication state. The LEDs are numbered 5 to 1 from left to right to
25
26
27
28
29
30
31
DP
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
2
3
4
5
6
7
8
Segment No. indicates the address of the HCB at each
floor for Modbus communication with the MCB.
5
4
3
2
1
CANbus communication state from strong to weak
Best
Interrupted
Monitoring CANbus
Communication state between
the CTB and the MCB
Segment ON:
communication normal
Segment OFF: communication abnormal
F5-32 communication state monitoring
Exam
ple
Communication state displayed by the LEDs
communication of addresses 1, 5, 6, 7, 12, 15, 16, 18, 19, 21, 22, 23, 25, 26 and 27
is abnormal, and Modbus communication of other addresses is normal. CANbus
communication state displayed by the LED is 3, indicating a little interference with
communication.
25
26
27
28
29
30
31
DP
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
2
3
4
5
6
7
8
Example of LED display indicating the communication state
