1 Servo System Selection
1
Item Description
Performance
Speed and
torque control
performance
Speed range
1:5500(lowerlimitofspeedshouldallowthedriveto
run with rated torque and load)
Speed loop bandwidth 3,000 Hz
Torque control accuracy
(repeatability)
±2%
Soft startup time setting 0–60s (acceleration and deceleration can be set)
Position control
performance
Positioning time 1 ms–10 ms
Input/Output
signal
Digital input
signal
Allowing signal
allocation change
24-channel DI (shared by multiple axes, with 16
channels available for high-speed probe function)
P-OT (positive limit switch), N-OT (negative limit switch),
HomeSwitch (home switch), TouchProbe1 (Probe1)
TouchProbe2 (Probe2)
Digital output
signal
Allowing signal
allocation change
6-channel DO (shared by multiple axes), DO load
capacity 50 mA and voltage range 5 V–30 V
S-RDY (servo ready), TGON (motor rotation output),
WARN (warning), ALM (fault)
Built-in
functions
Overtravel (OT) prevention
The drive slows down and stops when P-OT and N-OT
act.
Protection functions
Overcurrent, overvoltage, undervoltage, overload, main
circuitdetectionabnormal,heatsinkoverheat,power
supply phase loss, overspeed, encoder abnormal, CPU
abnormal, parameter abnormal, etc.
LED display Main circuit CHARGE indicator, 6-digit LED display
Vibration suppression
Four notches that can suppress mechanical resonance
of the 50–4,000 Hz frequency are available on each
axis, with 2 of them allowing adaptive setting. Both
themiddle-highfrequencyvibrationsuppressionlter
(that can suppress mechanical/system vibration of the
30–1,000 Hz frequency) and the low frequency vibration
suppressionlter(thatcansuppressmachinetable/end
vibration of the 1–100 Hz frequency) are available.
Communication protocol Ethernet, EtherCAT
Dynamicbrake
Built-indynamicbrakeforemergencybrakingincaseof
an abnormality
Brakepowersupply
Theoutputofbuilt-inbrakepowersupplymustbe
connected to an external 24 V power supply via the
CN7port.Thebrakecoilcanbeconnecteddirectlyto
theBR+andBR–ports.
Others Gain adjustment, alarm record, jog running
