3.6.2 Selection of Communication Cables
Selection principle
Specication Supplier
0.2 m–10 m Inovance
More than 10 m Haituo
Basic information about EtherCAT communication cables of Inovance
Cablemodelsareasfollows:
S6-L-T04-3.0
Cable Length (Unit: m)
Mark
0.2 m0.2
0.3 m0.3
0.5 m0.5
ImplicationMark
Product SeriesMark
S6 seriesS6
ImplicationMark
Cables (Line)L
ImplicationMark
Communication cables
T
EtherCAT multi-device
communication cables
04
Length
1.0 m1.0
Mark
2.
0 m2
.0
3.0 m3.0
5.0 m5.0
Length
10.0 10.0 m
Cableorderinginformation:
Material Code Cable Size Length (m)
15040261 S6-L-T04-0.3 0.3
15040262 S6-L-T04-3.0 3.0
15041960 S6-L-T04-0.2 0.2
15041961 S6-L-T04-0.5 0.5
15041962 S6-L-T04-1.0 1.0
15041963 S6-L-T04-2.0 2.0
15041964 S6-L-T04-5.0 5.0
15041965 S6-L-T04-10.0 10.0
Cablesof10mlongorshorter:mustbepurchasedfromInovance;
Cableslongerthan10m:tobepurchasedfromHaituo
Specicationandcharacteristics:
Item Detailed Description
ULcertication ComplywithULcertication
CAT.5E cable CAT.5E cable
Double shield Braided shield (coverage 85%), aluminum foil shield (coverage 100%)
Environmental adaptability
Workingambienttemperature:–30–+60
℃
; resistant to industrial oil and
corrosiveacidandalkali.
EMC testing standard GB/T 24808-2009
