Inovance SV820N Series - 2.1.3 Installation Method

- 25 -
2 Installation
2
A multi-axis system requires units to be lined up along the top.
TotaketheheatdissipationandcoolingrequirementsonunitsRunsettingsintofullconsideration,sufcient
installationclearancesshouldbereservedbyreferringtodatainthegurebelow:
Figure 2-4 Installation clearances
≥ 20 mm
≥ 50 mm
≥ 20 mm
≥ 50 mm
≥ 145 mm
Installationdirection:Theproductmustonlybeinstalledvertically,nothorizontallyorononeside.
