Instron 5960 Series User Manual

2-11
Series 5960 Dimensions
Product Support: www.instron.com
Series 5960 Dimensions
Standard Frame Dimensions
Load frame dimensions for all standard configuration dual column table model load frames
are listed in Table 2-5 on page 2-11. See Figure 2-1 on page 2-13 to match the letter
designations in the table.
Table 2-4. 5960 Optional Frame Combinations
Optional
Configuration
Load Frame Model
5965 5966 5967 5969
Extra Wide No No Yes No
Extra Height Yes Yes Yes Yes
Extra Wide + Extra
Height
No No Yes No
Second Test Space Yes Yes Yes Yes
Extra Height with
Second Test Space
Yes Yes Yes No
Extra Wide with
Second Test Space
No No No No
Table 2-5. Series 5960 Standard Configuration Dimensions
Letter
Designation Description Dimension - mm (inch)
A Across columns 720 (28.3)
B Column depth 140 (5.5)
C Horizontal test daylight 418 (16.5)
D Top plate thickness 52 (2.0)
E Crosshead thickness
5965/5966
5967/5969
76 (3.0)
120 (4.7)
F Space required to open controller door 148 (5.8)
