Chapter: Requirements and Specifications
2-12 M10-16248-EN
Extra Height Configuration
The dimensions of the extra height models are the same as for standard models, except for
the overall height dimension N, which is 2159 mm (85.0 in).
G Base beam height from table 190 (7.5)
H Gap for feet - nominal setting 25 (1.0)
J1 Crosshead position
5965/5966 Minimum
5965/5966 Maximum
5967/5969 Minimum
5967/5969 Maximum
116 (4.6)
1256 (49.5)
72 (2.8)
1212 (47.7)
J2 Not applicable
K Overall depth 725 (28.5)
L Front of base to test center 265 (10.4)
M Motor cover height 403 (15.9)
N Overall height (maximum) 1634 (64.3)
P Overall width 779 (30.7)
Q Coupling pin to base 59 (2.3)
R Load cell pin to crosshead
with 2580 Series load cells 500N, 1kN, 2kN
with 2580 Series load cell 5kN
with 2580 Series load cells 10kN, 30kN, 50kN
91 (3.58)
101 (3.98)
122 (4.80)
S Top plate width 180 (7.1)
Table 2-5. Series 5960 Standard Configuration Dimensions
Letter
Designation Description Dimension - mm (inch)
