Instron 5960 Series User Manual

2-17
Load Frame Weights
Product Support: www.instron.com
Extra Height with Second Test Space Configuration
The dimensions of the extra height with second test space model are the same as for the
standard model, except for those listed in Table 2-9 on page 2-17.
Load Frame Weights
P Overall width 779 (30.7)
Q Coupling pin to base 59 (2.3)
R Load cell pin to crosshead
with 2525-800 Series load cells up to 10 kN
with 2525-800 Series 30 kN or 50 kN load cell
133 (5.2)
142 (5.6)
Table 2-8. 5960 Second Test Space Configuration Dimensions (Continued)
Letter
Designation Description Dimension mm (inch)
Table 2-9. 5960 Extra Height with Second Test Space Dimensions
Designation Description Dimension mm (inch)
J1 Crosshead position
Minimum
Maximum
192 (7.5)
1832 (72.1)
J2 Crosshead position with
second test space
Minimum
Maximum
128 (5.0)
1756 (69.1)
N Overall height 2182 (85.9)
Table 2-10. Weight - Standard Configurations
Model Number
Weight
of Load Frame
5965 146 kg (322 lb)
5966 146 kg (322 lb)
