Chapter: Maintenance
5-10 M10-16248-EN
Tool spanner, open 12/13 mm 80-4-25 1 Leveling the load frame
Tool socket driver 80-3-50 1 Used to attach 2580 Series load cell
(10kN) to 5966 frame
Retainer clip for 1/2 diameter pin T1223-1053 2 Prevents the grip coupling pin from
sliding out during testing
Accessories slot T-nut T1697-1307 3 Installing accessories onto the
column cover
Retaining pin, grip coupling T29-515 1 Secures the grip coupling
Ground cable A712-213 1 Used to connect the frame to a
suitable ground where the mains
power supply is not grounded
Cable Ethernet Cat5E 10ft
Crossover
144-1-1052 1 Connects the frame controller to the
computer
Converter Type D to Type O 2501-346 1 Allows use of accessories with Type
O interface.
Additional parts for frames with second test space only:
Screw, M10 x 70 201R239 1 Attaches 2580 Series load cells
(500N, 1kN, 2kN and 5kN) to 5965
and 5966 frames
Screw, M16 x 75 201R311 1 Attaches 2580 Series load cell (10kN)
to 5966 frame
Screw, M10 x 30 201V55 3 Load cell attachment
M10 spacer T604-90 1 Use with M10 screws for load cell
attachment
M16 washer 610J12 1 Use with M16 screws for load cell
attachment
Compression spring
3/4 OD x 2 in length
66-4-5 1 Removes slack on lower grips with no
checknut
Pin 3mm diameter, 10mm long 705K84 1 Load cell anti-rotation pin
Pin 3mm diameter, 12mm long 705K85 1 Load cell anti-rotation pin
Retainer clip for 1/2 diameter pin T1223-1053 1 Prevents the grip coupling pin from
sliding out during testing
Table 5-2. 5965 and 5966 Ancillary Parts
Description
Part
Number Quantity Purpose
