Chapter: Maintenance
5-12 M10-16248-EN
Locating ring adapter T604-101 1 Adapter for load cell locating ring -
40mm/20mm - used for 2580 Series
load cells (10kN, 30kN, 50kN)
M10 spacer T604-90 1 Use with M10 screws for load cell
attachment
M16 washer 610J12 3 Use with M16 screws for load cell
attachment
Fuse, 10A Time lag, 5 x 20mm
glass high surge
27-2-233 2 Protection from electrical surges
Compression spring 66-5-6 1 Removes slack on lower grips with no
checknut
Compression spring
3/4 OD x 2 in length
66-4-5 1 Removes slack on lower grips with no
checknut
Hex wrench key set,
1.5 to 10 mm
80-1-1011 1 Tools for maintaining the frame and
installation of accessories
8 mm bit - 1/2 drive 80-3-13 1 Torquing M10 bolts on various load
string components
Tool spanner, open 12/13 mm 80-4-25 1 Leveling the load frame
Tool socket driver 80-3-50 1 Used to attach 2580 Series load cell
(10kN) to 5966 frame
Torque wrench 80-9-9 1 Provides correct installation torque for
load cell attachment screw
Retainer clip for 1/2 diameter pin T1223-1053 2 Prevents the grip coupling pin from
sliding out during testing
Accessories slot T-nut T1697-1307 3 Installing accessories onto the
column cover
Retaining pin, grip coupling T29-515 1 Secures the grip coupling
Ground cable A712-213 1 Used to connect the frame to a
suitable ground where the mains
power supply is not grounded
Cable Ethernet Cat5E 10ft
Crossover
144-1-1052 1 Connects the frame controller to the
computer
Converter Type D to Type O 2501-346 1 Allows use of accessories with Type
O interface.
Table 5-3. 5967 and 5969 Ancillary Parts
Description
Part
Number Quantity Purpose
