DGC6 – UserManual
In the column IN (source), you can set the relay assigned to an alarm in the menu SP Parameter.
In the column OUT (target), you can enter the relay needed in addition.
Note:
Manual intervention in the menu Relay Status or override in external ON or OFF by external DI do not count as alarm
status, so they do only a󰀨ect the IN relay. If this is also desired for the OUT relay, it has to be congured separately for
each OUT relay.
Number Description Default Status Function
0-30
0-96
IN AR Relay
IN SR Relay
0
0 = Function o󰀨
X = Relay X should be multiplied (information source).
0-30
0-96
OUT AR Relay
OUT SR Relay
0
0 = Function o󰀨
X = Relay X (target) should switch together with IN relay.
Example 1:
3 relay contacts are needed with the same e󰀨ect of relay 3, (see assignment of the relays in chapter SP Parameters.)
Entry: 1: IN AR3 OUT SR2
Entry: 2: IN AR3 OUT AR8
If relay 3 is activated via an alarm, relays AR3, SR2 and AR8 switch at the same time.
IN OUT
1: AR 3 SR 2.
IN OUT
2: AR 3 AR 8.
Example 2:
2 relay contacts each are needed from 3 relays (for ex. AR7, AR8, AR9).
Entry: 1: IN AR7 OUT AR12 (Relay 12 switches at the same time with relay 7)
Entry: 2: IN AR8 OUT AR13 (Relay 13 switches at the same time with relay 8)
Entry: 3: IN AR9 OUT AR14 (Relay 14 switches at the same time with relay 9)
This means that relay AR7 switches with AR12; AR8 with AR13; AR9 with AR14.
IN OUT
1: AR 7 AR 12.
IN OUT
2: AR 8 AR 13.
IN OUT
3: AR 9 AR 14.
The two examples can be mixed up, too.
