Intel 1000BASE-T User Manual

1000Base-T Test Fixtures and Calibration Load Fixtures
1000BASE-T/100BASE-TX/10BASE-T Physical Layer Compliance Tests Manual
104 Intel Confidential
Figure 24-1. 40-32 Schematic
1 2
2 1
1 2
49.9 Ohms
47.5 Ohms 47.5 Ohms
A
Pdf
1 2
2 1
1 2
2 1
49.9 Ohms
47.5 Ohms 47.5 Ohms
B Pdf
1 2
2 1
1 2
2 1
49.9 Ohms
47.5 Ohms 47.5 Ohms
C Pdf
1 2
2 1
1 2
2 1
49.9 Ohms
47.5 Ohms 47.5 Ohms
D Pdf
TXP SHIELD TXN RXP NC1 NC2 RXN NC3 NC4 SHIELD
1 2 3 4 5 6 7 8
2 1
RJ-45 Mate
