Mechanical Drawings
42
Thermal and Mechanical Design Guide
Figure 22. (G)MCH Reference Heatsink for ATX Platforms – Wire Preload Clip
8 7 6 5 4 3 2
H
G
F
E
D
C
B
A
8 7 6 5 4 3 2 1
H
G
F
E
D
C
B
A
A
46.6
0.5
1.835
.019[]
19.3 0.5
.760
.019[]
27.3 0.5
1.075
.019[]
2X 90
4X R 1.8
.071[]
4 2.8
.110[]
2X 4 36.7
1.445[]
4 128.6 3
64.3
THIS DRAWING CONTAINS INTEL CORPORATION CONFIDENTIAL INFORMATION. IT IS DISCLOSED IN CONFIDENCE AND ITS CONTENTS
MAY NOT BE DISCLOSED, REPRODUCED, DISPLAYED OR MODIFIED, WITHOUT THE PRIOR WRITTEN CONSENT OF INTEL CORPORATION.
REVISION HISTORY
ZONE REV DESCRIPTION DATE APPROVED
- A INITIAL RELEASE 09/06/05 -
D29082 1 A
DWG. NO SHT. REV
DEPARTMENT
R
CORP.
2200 MISSION COLLEGE BLVD.
P.O. BOX 58119
SANTA CLARA, CA 95052-8119
TMI
TITLE
PRELOAD, PWSH, BW, ATX
SIZE DRAWING NUMBER REV
A1 D29082 A
SCALE:
3
DO NOT SCALE DRAWING
SHEET
1
OF
1
SEE NOTESSEE NOTES
FINISHMATERIAL
09/06/05DANA GRINDLE
DATEAPPROVED BY
09/06/05DANA GRINDLE
09/06/05C.BERMENSOLO
DATECHECKED BY
08/08/05KGTAN
DATEDRAWN BY
07/10/05KGTAN
DATEDESIGNED BY
UNLESS OTHERWISE SPECIFIED
INTERPRET DIMENSIONS AND TOLERANCES
IN ACCORDANCE WITH ASME Y14.5M-1994
THIRD ANGLE PROJECTION
PARTS LIST
DESCRIPTIONPART NUMBER
ITEM NO
QTY
SPRING, HSS, 8.00 LBI, 65.00MMD29082-001TOP
NOTES:
1. THIS DRAWING TO BE USED IN CORRELATION WITH SUPPLIED 3D
DATABASE FILE. ALL DIMENSIONS AND TOLERANCES ON THIS
DRAWING TAKE PRECEDENCE OVER SUPPLIED FILE AND ARE
APPLICABLE AT PART FREE, UNCONSTRAINED STATE UNLESS
INDICATED OTHERWISE.
2. TOLERANCES ON DIMENSIONED AND UNDIMENSIONED
FEATURES UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS.
TOLERANCES: LINEAR 0.25
ANGLES: 3
3. MATERIAL:
TYPE: ASTM A228 MUSIC WIRE 1.8 0.1MM 4
PLATING: ELECTRO-LESS NICKEL OR EQUIVALENT UPON
INTEL APPROVAL.
4 CRITICAL TO FUNCTION DIMENSION
5. MARK WITH INTEL P/N AND REVISION PER INTEL MARKING
STANDARD 164997; PER SEC 3.8 (POLYETHYLENE BAG)
6. REMOVE ALL SHARP EDGES AND BURRS.
7. ALL DIMENSIONS SHOWN SHALL BE MEASURED FOR FAI
8. ALL SECONDARY UNIT DIMENSIONS ARE FOR REFERENCE ONLY.
