1 Product Description
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the major features of the board.
Table 2. Feature Summary
Form Factor
Mini-ITX (6.7 inches by 6.7 inches [170.18 millimeters by 170.18 millimeters])
Processor Fanlessly-cooled, soldered-down Dual-Core Intel
®
Atom™ Processor N2800 with
integrated graphics and integrated memory controller
Memory
• Two 204-pin DDR3 SDRAM Small Outline Dual Inline Memory Module (SO-
DIMM) sockets
• Support for DDR3 800 MHz and DDR3 1066 MHz SO-DIMMs
Note: Higher speed SO-DIMMs supported at 1066 MHz if supported by the
memory module.
• Support for up to 4 GB of system memory on a single SO-DIMM (or two
2 GB SO-DIMMs)
Chipset
Intel
®
NM10 Express Chipset
Graphics
• Integrated graphics:
Digital displays (High Definition Multimedia Interface* (HDMI*))
Analog displays (VGA)
Internal flat panel displays:
LVDS
eDP (Embedded DisplayPort*)
• External graphics:
One PCI Express 1.0a x1 graphics add-in card connector
Audio
• 2+2 Intel
®
High Definition (Intel
®
HD) audio via the Realtek* ALC888S audio
codec
Analog stereo line-out (back panel jack)
In-chassis stereo speakers support (3 W/3 Ω via internal header)
S/PDIF digital audio output (internal header)
DMIC digital microphone input (internal header)
Analog line-in (back panel jack)
Front panel Intel HD Audio/AC’97 headphones/mic support (internal
header)
• 8-channel (7.1) Intel High Definition Audio via the HDMI interface
continued
