Intel Desktop Board DN2800MT Technical Product Specification
20
1.4 System Memory
The board has two 204-pin SO-DIMM sockets and supports the following memory
features:
• 1.5V DDR3-800 and DDR3-1066 SO-DIMMs with gold-plated contacts
• Unbuffered, non-ECC, Raw Card B (1Rx8) and Raw Card-F (2Rx8) SO-DIMMs only
• Single-sided or double-sided modules
• 4 GB maximum total system memory
• Serial Presence Detect
• DDR3 800 MHz and DDR3 1066 MHz SO-DIMMs
(Higher speed SO-DIMMs supported at 1066 MHz if supported by the memory
module.)
NOTE
Due to fanless thermal constraints, system memory must have an operating
temperature rating of 85
o
C.
The board is designed to be fanlessly cooled in a properly ventilated chassis. Chassis
venting locations are recommended above the system memory area for maximum
heat dissipation effectiveness.
NOTE
To be fully compliant with all applicable DDR SDRAM memory specifications, the board
should be populated with SO-DIMMs that support the Serial Presence Detect (SPD)
data structure. This allows the BIOS to read the SPD data and program the chipset to
accurately configure memory settings for optimum performance. If non-SPD memory
is installed, the BIOS will attempt to correctly configure the memory settings, but
performance and reliability may be impacted or the SO-DIMMs may not function under
the determined frequency.
