Table 12 lists the connectors and headers identified in Figure 13.
Table 13. Connectors and Headers Shown in Figure 13
Item/callout
from Figure 13 Description
Connector Information
Board Connector Mating Plug
A Debug connector 1x11, 1.25mm-pitch
B System fan header 3-wire fan
C Internal power connector Molex* 5566-2 Molex 5557-02R
D SATA data connector 7-pin SATA (male) 7-pin SATA (female)
E SATA power connector 15-pin SATA (male) 15-pin SATA (female)
F PCI Express Half-Mini Card slot
G SATA data connector 7-pin SATA (male) 7-pin SATA (female)
H LVDS connector ACES* 88341-40 ACES 88441-40
Starconn* 107F40
I FPD brightness connector Foxconn* HF5508 JWT* A2001H02-8P
J Flat panel voltage selection header 2x3, 2.54mm-pitch Jumper
K Backlight inverter voltage selection
header
2x3, 2.54mm-pitch Jumper
L Front panel header 2x5, 2.54mm-pitch
M Front panel audio header 2x5, 2.54mm-pitch
N Front panel dual-port USB header 2x5, 2.54mm-pitch
O Front panel dual-port USB header 2x5, 2.54mm-pitch
P Serial port header 2x5, 2.54mm-pitch
Q Serial port header 2x5, 2.54mm-pitch
R Parallel port header 2x13, 2.54mm-pitch
S DMIC header 1x5, 2.54mm-pitch
T PCI Express Full-/Half-Mini Card slot
U Custom Solutions header 2x4, 2.00mm-pitch
V PCI Express 1.0a x1 connector
W S/PDIF header 1x4, 2.54mm-pitch
X Internal stereo speakers header JS*-1125-04 JWT* A2001H02-4P
