Intel Desktop Board DN2800MT Technical Product Specification
52
Table 22. Serial Port Headers
Pin Signal Name Pin Signal Name
1 DCD (Data Carrier Detect) 2 RXD# (Receive Data)
3 TXD# (Transmit Data) 4 DTR (Data Terminal Ready)
5 Ground 6 DSR (Data Set Ready)
7 RTS (Request To Send) 8 CTS (Clear To Send)
9 RI (Ring Indicator) 10 Key (no pin)
Table 23. Parallel Port Header
Pin Standard Signal Name EPP Signal Name
1 STROBE# WRITE#
2 AUTOFD# DATASTB#
3 PD0 PD0
4 FAULT# FAULT#
5 PD1 PD1
6 INT# RESET#
7 PD2 PD2
8 SLCTIN# ADDRSTB#
9 PD3 PD3
10 GROUND GROUND
11 PD4 PD4
12 GROUND GROUND
13 PD5 PD5
14 GROUND GROUND
15 PD6 PD6
16 GROUND GROUND
17 PD7 PD7
18 GROUND GROUND
19 ACK# INTR
20 GROUND GROUND
21 BUSY WAIT#
22 GROUND GROUND
23 PERROR PE
24 GROUND GROUND
25 SELECT SELECT
26 KEY (no pin) KEY (no pin)
