Intel DN2800MT User Manual

Technical Reference
75
2.9 Environmental
Table 41 lists the environmental specifications for the board.
Table 42. Environmental Specifications
Parameter Specification
Temperature
Non-Operating
-20 °C to +70 °C
Operating (ambient,
outside chassis)
0 °C to +35 °C
Operating
(inside chassis)
0 °C to +55 °C
Shock
Unpackaged 50 g trapezoidal waveform
Velocity change of 170 inches/s²
Packaged Half sine 2 millisecond
Product Weight (pounds) Free Fall (inches) Velocity Change (inches/s²)
<20 36 167
21-40 30 152
41-80 24 136
81-100 18 118
Vibration
Unpackaged 5 Hz to 20 Hz: 0.01 g² Hz sloping up to 0.02 g² Hz
20 Hz to 500 Hz: 0.02 g² Hz (flat)
Packaged 5 Hz to 40 Hz: 0.015 g² Hz (flat)
40 Hz to 500 Hz: 0.015 g² Hz sloping down to 0.00015 g² Hz
NOTE
Maximum operating temperatures based on fanless chassis configuration
(tests performed with Morex* T-1620 thin-mITX chassis).
