Intel DN2800MT User Manual

Technical Reference
49
2.2.3 Connectors and Headers (Bottom)
Figure 14 shows the locations of the connectors and headers on the bottom-side of the
board.
Figure 14. Connectors and Headers (Bottom)
Table 13 lists the connectors and headers identified in Figure 14.
Table 14. Connectors and Headers Shown in Figure 14
Item/callout
from Figure 14 Descript
ion
Connector Information
Board Connector Mating Plug
A eDP connector ACES 50203-040 ACES 88441-40
Starconn 107F40
