Intel Desktop Board DN2800MT Technical Product Specification
40
1.13.2.1 Power Input
When resuming from an AC power failure, the computer returns to the power state it
was in before power was interrupted (on or off). The computer’s response can be set
using the Last Power State feature in the BIOS Setup program’s Boot menu.
For information about Refer to
The location of the internal power connector Figure 13, page 47
The signal names of the internal power connector Table 33, page 58
1.13.2.2 Fan Header
The function/operation of the fan header is as follows:
• The fan is on when the board is in the S0 state
• The fan is off when the board is off or in the S3, S4, or S5 state.
• The fan header is wired to a fan tachometer input of the hardware monitoring and
fan control ASIC.
• The fan header supports closed-loop fan control that can adjust the fan speed as
needed.
• The fan header has a +12 V DC connection.
• The fan header supports 3-wire (voltage controlled) fans.
For information about Refer to
The location of the fan header Figure 13, page 47
The location of the fan header and sensor for thermal monitoring Figure 9, page 36
