Product Description
21
Table 4 lists the supported SO-DIMM configurations.
Table 5. Supported Memory Configurations
Raw Card
Version
SO-DIMM
Capacity
DRAM Device
Technology
DRAM
Organization
# of DRAM
Devices
B
1 GB 1 Gb 128 M x 8 8
2 GB 2 Gb 256 M x 8 8
F
2 GB 1 Gb 128 M x 8 16
4 GB 2 Gb 256 M x 8 16
Note: System memory configurations are based on availability and are subject to change.
For information about… Refer to:
Tested Memory http://support.intel.com/support/motherboards/desktop/sb
/CS-025414.htm
Figure 4 illustrates the SO-DIMM configuration.
Figure 4. SO-DIMM Configuration
