Intel Desktop Board DN2800MT Technical Product Specification
66
2.5 Mechanical Considerations
2.5.1 Form Factor
The board is designed to fit into a Mini-ITX form-factor chassis. Figure 21 illustrates
the mechanical form factor for the board. Dimensions are given in inches
[millimeters]. The outer dimensions are 6.7 inches by 6.7 inches [170.18 millimeters
by 170.18 millimeters]. Location of the I/O connectors and mounting holes are in
compliance with the ATX specification.
NOTE
The board is designed to have a total height of less than 20 mm from the underside of
the board to the top of its tallest components, including all back panel I/O ports,
internal connectors, installed system memory, and factory-installed thermal solutions,
in compliance with thin mini-ITX requirements per version 2 of the Mini-ITX Addendum
to the microATX Motherboard Interface Specification.
For more information about Refer to
Thin mini-ITX form factor
http://www.formfactors.org/developer%5Cspecs%5CMini_ITX_
Spec_V2_0.pdf
