Intel Desktop Board DN2800MT Technical Product Specification
16
Table 2 lists the components identified in Figure 1.
Table 3. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Debug connector
B Battery
C Back panel connectors
D System fan header
E Internal power connector
F Intel NM10 Express Chipset
G BIOS Setup configuration jumper block
H SATA data connector
I SATA power connector
J PCI Express Half-Mini card slot
K SATA data connector
L Intel Atom processor and heatsink
M Flat panel display connectors
N DDR3 SO-DIMM 0 socket
O DDR3 SO-DIMM 1 socket
P Front panel header
Q Front panel audio header
R Front panel dual-port USB headers
S Standby power LED
T Serial port headers
U Parallel port header
V DMIC header
W PCI Express Full-/Half-Mini Card slot
X Custom Solutions header
Y PCI Express 1.0a x1 connector
Z S/PDIF header
AA Internal stereo speakers connector
