Intel Desktop Board DN2800MT Technical Product Specification
46
2.2.1 Back Panel Connectors
Figure 12 shows the location of the back panel connectors for the board.
Item Description
A DC input jack
B USB ports
C LAN connector
D VGA connector
E High-current/fast charging USB ports
F HDMI connector
G Analog line out
H Microphone in
Figure 12. Back Panel Connectors
