Intel
®
Core
TM
2 Duo E6400, E4300, and Intel
®
Pentium
®
Dual-Core E2160 Processor
October 2007 TDG
Order Number: 315279 - 003US 21
Thermal Metrology—Intel
®
Core
TM
2 Duo E6400, E4300, and Intel
®
Pentium
®
Dual-Core E2160
Processor
3.0 Thermal Metrology
This section discusses guidelines for testing thermal solutions, including measuring
processor temperatures. In all cases, the thermal engineer must measure power
dissipation and temperature to validate a thermal solution. To define the performance
of a thermal solution the "thermal characterization parameter", Ψ ("psi") will be used.
3.1 Characterizing Cooling Performance Requirements
The idea of a "thermal characterization parameter", Ψ ("psi"), is a convenient way to
characterize the performance needed for the thermal solution and to compare thermal
solutions in identical situations (same heat source and local ambient conditions). The
thermal characterization parameter is calculated using total package power.
Note: Heat transfer is a three-dimensional phenomenon that can rarely be accurately and
easily modeled by a single resistance parameter like Ψ.
The case-to-local ambient thermal characterization parameter value (Ψ
CA
) is used as a
measure of the thermal performance of the overall thermal solution that is attached to
the processor package. It is defined by the following equation, and measured in units of
°C/W:
Equation 1. Ψ
CA
= (T
C
- T
A
) / P
D
Where:
Ψ
CA
= Case-to-local ambient thermal characterization parameter (°C/W)
T
C
= Processor case temperature (°C)
T
A
= Local ambient temperature in chassis at processor (°C)
P
D
= Processor total power dissipation (W) (assumes all power dissipates
through the IHS)
The case-to-local ambient thermal characterization parameter of the processor, Ψ
CA
, is
comprised of Ψ
CS
, the thermal interface material thermal characterization parameter,
and of Ψ
SA
, the sink-to-local ambient thermal characterization parameter:
Equation 2. Ψ
CA
= Ψ
CS
+ Ψ
SA
Where:
Ψ
CS
= Thermal characterization parameter of the thermal interface material
(°C/W)
Ψ
SA
= Thermal characterization parameter from heatsink-to-local ambient
(°C/W)
Ψ
CS
is strongly dependent on the thermal conductivity and thickness of the TIM
between the heatsink and IHS.

Intel E2160 - Cpu Pentium Dual-Core 1.80Ghz Fsb800Mhz 1M Lga775 Tray Specifications

General

Processor Model	Intel Pentium Dual-Core E2160
Clock Speed	1.80 GHz
FSB Speed	800 MHz
L2 Cache	1 MB
Socket	LGA 775
Core Count	2
Thermal Design Power (TDP)	65 W
Core	Conroe
Manufacturing Process	65 nm
Virtualization Technology	No
Hyper-Threading	No
Turbo Boost	No
Instruction Set	MMX, SSE, SSE2, SSE3
Memory Types	DDR2
