Case Temperature Reference Metrology—Intel
®
Core
TM
2 Duo E6400, E4300, and Intel
®
Pentium
®
Dual-Core E2160 Processor
Appendix C Case Temperature Reference Metrology
C.1 Objective and Scope
This appendix defines a reference procedure for attaching a thermocouple to the IHS of
a 775-land LGA package for TC measurement. This procedure takes into account the
specific features of the 775-land LGA package and of the LGA775 socket for which it is
intended. The recommended equipment for the reference thermocouple installation,
including tools and part numbers are also provided. In addition, a video that shows the
process in real time - Thermocouple Attach Using Solder - Video CD-ROM - is available.
For information on case temperature reference setup, tool use, and approach, please
refer to Intel® Core™2 Duo Processor and Intel® Pentium® Dual Core Processor
Thermal and Mechanical Design Guidelines, Appendix D.

Intel E2160 - Cpu Pentium Dual-Core 1.80Ghz Fsb800Mhz 1M Lga775 Tray Specifications

General

Processor Model	Intel Pentium Dual-Core E2160
Clock Speed	1.80 GHz
FSB Speed	800 MHz
L2 Cache	1 MB
Socket	LGA 775
Core Count	2
Thermal Design Power (TDP)	65 W
Core	Conroe
Manufacturing Process	65 nm
Virtualization Technology	No
Hyper-Threading	No
Turbo Boost	No
Instruction Set	MMX, SSE, SSE2, SSE3
Memory Types	DDR2
