Intel® Server Board S1200SP Family Technical Product Specification
2
2 Overview
The Intel
®
Server Board S1200SP product family consist of S1200SPS and S1200SPL. The server boards are
monolithic printed circuit boards (PCBs) with features designed to support the pedestal or rack server markets.
These server boards are designed to support the Intel
®
Xeon
®
processor E3-1200 V5 and V6 product family.
Previous generation Intel
®
Xeon
®
processors are not supported. Many of the features and functions of these
three server boards are common. A board will be identified by name when a described feature or function is
unique to it.
2.1 Intel
®
Server Board S1200SP Family Feature Set
Table 1. Intel
®
Server Board S1200SP Feature Set
S1200SPL
S1200SPS
S1200SPO
Form Factor
MicroATX 9.6”x9.6” compliant form factor
Processor
 Support for one Intel
®
Xeon
®
E3-1200 V5 and V6 processor in an LGA 1151 Socket H4 package with
Thermal Design Power up to 80W
 S1200SPL supports Intel
®
Xeon
®
processor E3-1200 V5 and V6 processor graphics (GT2 or 4+2),
S1200SPS and S1200SPO supports Intel
®
Xeon
®
processor E3-1200 V5 and V6 without processor
graphics (GT0 or 4+0).
 8 GT/s point-to-point DMI 3.0 interface to PCH
Chipset
Intel® C236 Platform Controller
Hub (PCH) chipset
Intel® C232 Platform Controller
Hub (PCH) chipset
Intel® C236 Platform Controller
Hub (PCH) chipset
Memory
 Two memory channels, four memory DIMMs (Two memory DIMMs per channel)
 Support for 2133 MT/s Unbuffered (UDIMM DDR4 ECC memory)
Max Memory
64GB
Add-in PCI Express*
Slots and Module
Connectors Number
4
See Note.
3
See Note.
3
Add-in PCI Express*
Slots and Module
Connectors
Configuration
PCI Express* Gen3 x8 electrical
with x16 physical connector, from
processor
PCI Express* Gen3 x8 electrical
with x16 physical connector, from
processor
PCI Express* Gen3 x 8 electrical
with x16 physical connectors,
from processor
PCI Express* Gen3 x4 electrical
with x8 physical connector, from
PCH
PCI Express* Gen3 x4 electrical
with x8 physical connector, from
PCH
PCI Express* Gen3 x8 I/O module
connector, from processor
PCI Express* Gen3 x8 electrical
with x8 physical connector, from
processor
PCI Express* Gen3 x8 electrical
with x8 physical connector, from
processor
PCI Express* Gen3 x4 SAS
module connector, from PCH
PCI Express* Gen3 x4 SAS
module connector, from PCH
Ethernet
Two Gigabit Ethernet Ports through the two Intel
®
Ethernet Controller I210 PHYs
Storage
 8x SATA connectors at 6Gbps
 2x SGPIO
 1x HSBP I
2
C
 1x SATADOM connector
(SATA port 4)
 6x SATA connectors at 6Gbps
 1x SGPIO
 1x HSBP I
2
C
 1x SATADOM connector
(SATA port 4)
 8x SATA connectors at 6Gbps
 2x SGPIO
 1x HSBP I
2
C
 1x SATADOM connector
(SATA port 4)
SSD
1x 75 pin connector for
enterprise M.2 SATA SSD (2242
form factor)
N/A
1x 75 pin connector for
enterprise M.2 SATA SSD (2242
form factor)
SW RAID
 Intel
®
RSTe 4.x SW RAID through onboard SATA connectors provides SATA RAID 0/1/10/5.
 Intel
®
Embedded Server RAID Technology II through onboard SATA connectors provides SATA RAID
0/1/10 and optional RAID 5 support provided by the Intel
®
RAID Activation Key RKSATA4R5.
