Intel® Server Board S1200SP Family Technical Product Specification
31
3.5.2 Remote Keyboard, Video, Mouse, and Storage (KVMS)
The Integrated BMC contains a remote KVMS subsystem with the following features:
• USB 2.0 interface for Keyboard, Mouse and Remote storage such as CD/DVD ROM and floppy
• USB 1.1/USB 2.0 interface for PS2 to USB bridging, remote Keyboard and Mouse
• Hardware Based Video Compression and Redirection Logic
• Supports both text and Graphics redirection
• Hardware assisted Video redirection using the Frame Processing Engine
• Direct interface to the Integrated Graphics Controller registers and Frame buffer
• Hardware-based encryption engine
3.5.2.1 Integrated BMC Embedded LAN Channel
The Integrated BMC hardware includes two dedicated 10/100 Mb/s network interfaces. These interfaces are
not shared with the host system. At any time, only one dedicated interface may be enabled for management
traffic. The default active interface is the NIC 1 port.
For these channels, support can be enabled for IPMI-over-LAN and DHCP. For security reasons, embedded
LAN channels have the following default settings:
• IP Address: Static
• All users disabled
3.5.3 Graphics Controller and Video Support
The integrated graphics controller provides support for the following features as implemented on the server
board:
• Integrated Graphics Core with 2D Hardware accelerator
• DDR-3 memory interface supporting up to 128MB of memory, 16MB allocated to graphic
• Supports display resolutions up to 1920 x 1200 16bpp @ 60Hz
• High speed Integrated 24-bit RAMDAC
• Single lane PCI Express* host interface running at Gen 1 speed
The integrated video controller supports all standard IBM VGA modes. The following table shows the 2D
modes supported for both CRT and LCD.
Table 8. Onboard Video Resolution and Refresh Rate (Hz)
2D Video Mode Support (Color Bit)
