Intel® Server Board S1200SP Family Technical Product Specification
64
• Accessibility through IPMI interfaces – The platform debug file can be accessed using an external IPMI
interface (KCS or LAN).
• POST code sequence for the two most recent boots – This is a best-effort data collection by the BMC as
the BMC real-time response cannot guarantee that all POST codes are captured.
- SDR data.
- Signal debugging dumps, if available.
• Support for multiple debug files –The platform debug feature provides the ability to save data to two
separate files that are encrypted with different passwords.
- File #1 is strictly for viewing by Intel engineering and may contain BMC log messages (that is, syslog)
and other debug data that Intel FW developers deem useful in addition to the data specified in this
document.
- File #2 can be viewed by Intel partners who have signed an NDA with Intel and its contents are
restricted to specific data items specified in this with the exception of the BMC syslog messages and
power supply black box data.
6.11.15.1 Output Data Format
The diagnostic feature outputs a password-protected compressed HTML file containing specific BMC and
system information. This file is not intended for end-customer usage. This file is for customer support and
engineering only.
6.11.15.2 Output Data Availability
The diagnostic data is available on-demand from the embedded web server, KCS, or IPMI Over LAN commands.
6.11.15.3 Output Data Categories
The following tables list the data to be provided in the diagnostic output. For items in Table 17, this data is
collected on detection of CATERR, ERR2, PERR, SERR, and SMI timeout. The data in Table 18 is accumulated
for the three most recent overall errors.
Table 17. Diagnostic Data
Human-readable SEL listing
Human-readable sensor listing
POST codes for the two most recent boots
SMBIOS table for the current boot
