Intel® Server Board S1200SP Family Technical Product Specification
59
Table 16. Factory Configured PEF Table Entries
Event Filter
Number
Offset Mask
Events
1
Non-critical, critical and non-
recoverable
Temperature sensor out of
range
2
Non-critical, critical and non-
recoverable
Voltage sensor out of range
3
Non-critical, critical and non-
recoverable
Fan failure
4
General chassis intrusion
Chassis intrusion (security
violation)
5
Failure and predictive failure
Power supply failure
6
Uncorrectable ECC
BIOS
7
POST error
BIOS: POST code error
8
FRB2
Watchdog Timer expiration for
FRB2
9
Policy Correction Time
Node Manager
10
Power down, power cycle, and
reset
Watchdog timer
11
OEM system boot event
System restart (reboot)
12
Drive Failure, Predicted Failure
Hot Swap Controller
Additionally, the BMC supports the following PEF actions:
• Power off
• Power cycle
• Reset
• OEM action
• Alerts
The Diagnostic interrupt action is not supported.
6.11.10 LAN Alerting
The BMC supports sending embedded LAN alerts, called SNMP PET (Platform Event traps), and SMTP email
alerts.
The BMC supports a minimum of four LAN alert destinations.
6.11.10.1 SNMP Platform Event Traps (PETs)
This feature enables a target system to send SNMP traps to a designated IP address by means of LAN. These
alerts are formatted per the Intelligent Platform Management Interface Specification Second Generation v2.0.
A Modular Information Block (MIB) file associated with the traps is provided with the BMC firmware to facilitate
interpretation of the traps by external software. The format of the MIB file is covered under RFC 2578.
6.11.11 Alert Policy Table
Associated with each PEF entry is an alert policy that determines which IPMI channel the alert is to be sent.
There is a maximum of 20 alert policy entries. There are no pre-configured entries in the alert policy table
