Intel® Server Board S1200SP Family Technical Product Specification
72
Table 23. PMBUS SSI Connector Pin-out (J9F1)
Pin
IO
Signal Name
1
I
PMBUS_CLK
2
IO
PMBUS_DATA
3
O
IRQ_PMBUS_ALERT_N
4
GND
GND Return Sense
5
I
P3V3 Sense
Table 24. Battery Holder (BT2F1)
Pin
IO
Signal Name
1
PWR
P3V_BAT
2
GND
GND
8.3 System Management Headers
8.3.1 Intel
®
Remote Management Module 4 Lite Connector
The Intel® Server Board S1200SPL and S1200SPO provide a 7-pin Intel
®
RMM4 Lite connector and a stacked
connector that includes a USB 3.0 and a dedicated 1GbE RJ45 Management Port. The management port is
active with or without the RMM4 Lite key installed. The S1200SPS board does not support Intel
®
RMM4.
This server board does not support third-party management cards.
Note: This connector is not compatible with the previous generation Intel
®
Remote Management Modules
(Intel
®
RMM/RMM2/RMM3)
Table 25. Stacked connector of USB 3.0+ dedicated RJ45 Management Port Pin-out (JA5A1)
Pin
IO
Name
Pin
IO
Name
1
PWR
P5V_AUX
17
I
USB3_TX_DN
2
IO
USB2_DN
18
I
USB3_TX_DP
3
IO
USB2_DP
19
PWR
VCT
4
GND
GND
20
IO
MDI_P0
5
O
USB3_RX_DN
21
IO
MDI_N0
6
O
USB3_RX_DP
22
IO
MDI_P1
7
GND
GND
23
IO
MDI_N1
8
I
USB3_TX_DN
24
IO
MDI_P2
9
I
USB3_TX_DP
25
IO
MDI_N2
10
PWR
P5V_AUX
26
IO
MDI_P3
11
IO
USB2_DN
27
IO
MDI_N3
12
IO
USB2_DP
28
GND
GND
13
GND
GND
29
I
LED1_ANODE
14
O
USB3_RX_DN
30
O
LED1_CATHODE
15
O
USB3_RX_DP
31
IO
LED2_ANODE
16
GND
GND
32
IO
LED2_CATHODE
