Intel® Server Board S1200SP Family Technical Product Specification
82
8.5.8 SAS/ROC Module Connector
The Intel® Server Board S1200SPL and S1200SPO support Intel® Integrated RAID Module (known as SAS/ROC
module). The SAS/ROC module can be installed to the server board as shown below.
Figure 22. Installing Intel
®
Integrated RAID Module
The following table details the pin-out definition of the SAS/ROC module connector.
Table 46. I/O Module Connector Pin-out (J4J1)
Pin
IO
Signal Name
Pin
IO
Signal Name
79
PWR
3.3V
80
PWR
12V
77
PWR
3.3V
78
PWR
12V
75
PWR
3.3V
76
PWR
12V
73
PWR
3.3V
74
PWR
12V
71
NC
RSVD_SE
72
I
FRU/TEMP ADDR [0]
69
GND
GND
70
PWR
5V STBY
67
NC
RSVD_DP
68
I
FM_SAS_MODULE_EN_N
65
NC
RSVD_DN
66
PWR
3.3V STBY
63
GND
GND
64
O
LED_HDD_N
61
NC
RSVD_DP
62
O
FM_SAS_PRESENT_N
59
NC
RSVD_DN
60
O
WAKE#
57
GND
GND
58
I
PERST#
55
I
SMB CLK
56
GND
GND
53
IO
SMB DAT
54
I
rSASm REFCLK+ [0]
51
GND
GND
52
I
rSASm REFCLK- [0]
49
I
PCIe Gen3 Tn [7]
50
GND
GND
47
I
PCIe Gen3 Tp [7]
48
O
PCIe Gen3 Rn [7]
45
GND
GND
46
O
PCIe Gen3 Rp [7]
43
I
PCIe Gen3 Tn [6]
44
GND
GND
41
I
PCIe Gen3 Tp [6]
42
O
PCIe Gen3 Rn [6]
39
GND
GND
40
O
PCIe Gen3 Rp [6]
37
I
PCIe Gen3 Tn [5]
38
GND
GND
35
I
PCIe Gen3 Tp [5]
36
O
PCIe Gen3 Rn [5]
33
GND
GND
34
O
PCIe Gen3 Rp [5]
31
I
PCIe Gen3 Tn [4]
32
GND
GND
29
I
PCIe Gen3 Tp [4]
30
O
PCIe Gen3 Rn [4]
