Intel® Server Board S1200SP Family Technical Product Specification
18
• Gb and 8 Gb DDR4 DRAM device technologies are supported
- Using 4 Gb DRAM device technologies, the largest system memory capacity possible is 32 GB,
assuming Dual Channel Mode with four x8 dual ranked DIMM memory configuration
• The memory channels are named as Channel A and Channel B.
• The memory slots are named as Slot1 and Slot2 on each channel. Slot2 is the nearest from the processor
socket.
• DIMMs are named to reflect the channel and slot in which they are installed:
- Channel A, Slot1 is DIMM_A1.
- Channel A, Slot2 is DIMM_A2.
- Channel B, Slot1 is DIMM_B1.
- Channel B, Slot2 is DIMM_B2.
3.3.1 Supported Memory
• Single Ranked x8 unbuffered ECC
• Dual Ranked x8 unbuffered ECC
Table 3. UDIMM Support Guidelines
Ranks
Per
DIMM
and
Data
Width
Speed (MT/s) and Voltage Validated by
Slot per Channel (SPC) and DIMM Per Channel (DPC)
2400 (only Intel E3-1200 V6)
2400 (only Intel E3-1200 V6)
2400 (only Intel E3-1200 V6)
2400 (only Intel E3-1200 V6)
Note: Note: In case of using 2400 MHz memory modules with Intel E3-1200 v5 processor, the speed of the
memory will be reduced to 2133 MHz.
