13.3 Node Manager Health Event
A Node Manager Health Event message provides a runtime error indication about Intel
®
Intelligent Power Node Manager’s health.
Types of service that can send an error are defined as follows:
 Misconfigured policy Error reading power data
 Error reading inlet temperature
Table 95: Node Manager Health Event Sensor Typical Characteristics
Byte
Field
Description
8
9
Generator ID
002Ch or 602Ch – ME Firmware
11
Sensor Type
DCh = OEM
12
Sensor Number
19h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 73h (OEM)
14
Event Data 1
[7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Health Event Type = 02h (Sensor Node Manager)
15
Event Data 2
[7:4] – Error type
0-9 – Reserved
10 – Policy Misconfiguration
11 – Power Sensor Reading Failure
12 – Inlet Temperature Reading Failure
13 – Host Communication error
14 – Real-time clock synchronization failure
15 – Platform shutdown initiated by NM policy due to execution of action defined by Policy Exception Action
[3:0] – Domain Id
16
Event Data 3
If Error type = 10 or 15 <Policy Id>
