Processor Subsystem
System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
68 Intel order number G90620-002 Revision 1.1
Table 56: Processor ERR2 Timeout Sensor Typical Characteristics
Byte
Field
Description
11
Sensor Type
07h = Processor
12
Sensor Number
7Ch = Processor 1 ERR2 Timeout
7Dh = Processor 2 ERR2 Timeout
7Eh = Processor 3 ERR2 Timeout
7Fh = Processor 4 ERR2 Timeout
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 03h (“digital” discrete)
14
Event Data 1
[7:6] – 00b = Unspecified Event Data 2
[5:4] – 00b = Unspecified Event Data 3
[3:0] – Event Trigger Offset = 1h (State Asserted)
15
Event Data 2
Not used
16
Event Data 3
Not used
6.5.1 Processor ERR2 Timeout – Next Steps
1. Check the SEL for any other events around the time of the failure.
2. Take note of all IPMI activity that was occurring around the time of the failure. Capture a System BMC Debug Log as soon as you
can after experiencing this failure. This log can be captured from the Integrated BMC Web Console or by using the Intel
®
Syscfg
utility (syscfg /sbmcdl private filename.zip). Send the log file to your system manufacturer or Intel representative for failure
analysis.
6.6 Processor MSID Mismatch Sensor
The BMC supports a MSID Mismatch sensor for monitoring for the fault condition that will occur if there is a power rating
incompatibility between a baseboard and a processor.
The sensor is rearmed on power-on (AC or DC power on transitions).
