Sensor Cross Reference List
Revision 1.1 Intel order number G90620-002 13
3. Sensor Cross Reference List
This section contains a cross reference to help find details on any specific SEL entry.
3.1 BMC owned Sensors (GID = 0020h)
The following table can be used to find the details of sensors owned by the BMC.
Table 5: BMC owned Sensors
Sensor
Number
Sensor Name
Details Section
Next Steps
01h
Power Unit Status
(Pwr Unit Status)
Power Unit Status Sensor
Table 16: Power Unit Status Sensor – Sensor Specific Offsets – Next
Steps
02h
Power Unit Redundancy
(Pwr Unit Redund)
Power Unit Redundancy Sensor
Table 18: Power Unit Redundancy Sensor – Event Trigger Offset – Next
Steps
03h
IPMI Watchdog
(IPMI Watchdog)
IPMI Watchdog
Table 78: IPMI Watchdog Sensor Event Trigger Offset – Next Steps
04h
Physical Security
(Physical Scrty)
Physical Security
Table 74: Physical Security Sensor Event Trigger Offset – Next Steps
05h
FP Interrupt
(FP NMI Diag Int)
FP (NMI) Interrupt
FP (NMI) Interrupt – Next Steps
06h
SMI Timeout
(SMI Timeout)
SMI Timeout
SMI Timeout – Next Steps
07h
System Event Log
(System Event Log)
System Event Log Cleared
Not applicable
08h
System Event
(System Event)
System Event – PEF Action
System Event – PEF Action – Next Steps
09h
Button Sensor
(Button)
Button Sensor
Not applicable
