System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
Memory Subsystem
Revision 1.1 Intel order number G90620-002 75
Table 62: Sparing Redundancy State Sensor Typical Characteristics
Byte
Field
Description
8
9
Generator ID
0033h = BIOS SMI Handler
11
Sensor Type
0ch = Memory
12
Sensor Number
11h
13
Event Direction and
Event Type
[7] Event direction
0b = Assertion Event
1b = Deassertion Event
[6:0] Event Type = 0Bh (Generic Discrete)
14
Event Data 1
[7:6] – 10b = OEM code in Event Data 2
[5:4] – 10b = OEM code in Event Data 3
[3:0] – Event Trigger Offset
0h = Fully Redundant
2h = Redundancy Degraded
15
Event Data 2
Location
[7:4] = Sparing Domain
0-3 = Channel A-D for Socket
[3:2] = Reserved
[1:0] = Rank on DIMM
0-3 = Rank Number
16
Event Data 3
Location
[7:5]= Socket ID
0-3 = CPU1-4
[4:3] = Channel
0-3 = Channel A-D for Socket
[2:0] = DIMM
0-2 = DIMM 1-3 on Channel
