System Event Log Troubleshooting Guide for EPSD Platforms Based on Intel
®
Xeon
®
Processor E5 4600/2600/2400/1600/1400 Product Families
24 Intel order number G90620-002 Revision 1.1
3.2 BIOS POST owned Sensors (GID = 0001h)
The following table can be used to find the details of sensors owned by BIOS POST.
Table 6: BIOS POST owned Sensors
Sensor
Number
Sensor Name
Details Section
Next Steps
02h
Memory RAS Configuration Status
Memory RAS Configuration Status
Table 58: Memory RAS Configuration Status Sensor Typical
Characteristics
06h
POST Error
System Firmware Progress (Formerly Post
Error)
System Firmware Progress (Formerly Post Error) – Next Steps
09h
Intel
®
Quick Path Interface Link
Width Reduced
QPI Link Width Reduced Sensor
QPI Link Width Reduced Sensor – Next Steps
12h
Memory RAS Mode Select
Memory RAS Mode Select
Not applicable
83h
System Event
System Events
Not applicable
3.3 BIOS SMI Handler owned Sensors (GID = 0033h)
The following table can be used to find the details of sensors owned by BIOS SMI Handler.
Table 7: BIOS SMI Handler owned Sensors
Sensor
Number
Sensor Name
Details Section
Next Steps
01h
Mirroring Redundancy State
Mirroring Redundancy State
Mirroring Redundancy State Sensor – Next Steps
02h
Memory ECC Error
Memory Correctable and Uncorrectable
ECC Error
Table 64: Correctable and Uncorrectable ECC Error Sensor
Event Trigger Offset – Next Steps
03h
Legacy PCI Error
Legacy PCI Errors
Legacy PCI Error Sensor – Next Steps
04h
PCI Express* Fatal Error
PCI Express* Fatal Errors and Fatal Error #2
PCI Express* Fatal Error and Fatal Error #2 Sensor – Next
Steps
05h
PCI Express* Correctable Error
PCI Express* Correctable Errors
PCI Express* Correctable Error Sensor – Next Steps
